Syringe Heater Kit

Specification Notes:

• Available in 2 versions:
  • 1LG Heating Pad: 3.5" x 3.0" LxW (9 cm x 7.5 cm)
  • 5SP Heating Pad: 20" x 0.625" LxW (50 cm x 1.5 cm)
• Heater Kit includes control unit and primary syringe heater pad 1LG version or 5SP version.
• Multiple syringe heater pads can be attached to the control unit, under restricted conditions.
• Set point and other parameters retained in memory
• Computer interface
• Digitally sets the heater set point
• Controller will heat the syringe and hold the set temperature using an on/off or Thermo-Kinetic control algorithm.
• Dual temperature sensors in primary heating pad.
• Alarm modes with multiple layers of protection to prevent temperature overrun.
• Additonal heat protection for the pump may be needed when heating syringes above 100°C.
• If you are in a country where the voltage is above 120V, you must purchase a step-down transformer (Model: PWR-220-110-E) along with the Heater Kit.
• Detailed Description

Second Heating Pad

Third and Additional Heating Pads

Specification Notes:

• Only use identical primary and secondary heater pads together.
• Each syringe heater control unit uses only the primary heating pad to sense temperature. All secondary heater pads connected to that control unit function according to temperature at the primary heater pad.
• Careful consideration should be taken when using secondary/slave heater pads.
• For different temperatures or variable environments, use separate control units with primary heater pads.
• Plugging more than 12 syringe heater pads onto one controller is not recommended.
• Detailed Description

Ana-Box Closed Loop Analog Sensor Interface

• Vary the pumping rate in proportion to a variable voltage input
• Start or stop pump at set voltages
• Vary the pumping rate to maintain a voltage window
• Attaches to any pump in the NE-1000 or NE-9000 Series
• Click Here For A Detailed Description

---

Foot Switch

• Remote and/or hands free pump operation
• Start, stop, or send a signal to a pumping program
• 15 different configurations. Change configuration within a pumping program
• 20 foot cable
• Quick and easy setup
• Attaches to the TTL logic port on the pump
• Attach to any pump in the NE-1000 or NE-9000 Series

Hand Pendant

• Hand held pendant for remote operation of pump
• Functions identically to Foot Switch
• 10 foot cable
• Attach to any pump in the NE-1000 or NE-9000 Series

---

Real-Time Clock Control

• Schedule dispenses at preset times or day of week
• Start, stop, or send a signal to a pumping program at preset times
• Up to 16 On/Off settings, plus manual control
• 30" Cable attaches to the TTL logic port on the pump
• Mountable controller
• Attach to any pump in the NE-1000 or NE-9000 Series

BNC Trigger Cable

• Cable to connect TTL Trigger input to a BNC output
• Functions identically to Foot Switch
• 6 foot cable
• Attach to any pump in the NE-1000 or NE-9000 Series

Limit Switch

• Adds a limit switch to automate refill or dispense limits after a power on
• Attaches to a guide rod. Fully adjustable
• Cable attaches to the TTL logic port on the pump
• Programmable operation within a pumping program

Extender Cable

• 100 foot extension cable for TTL logic port
• Works with foot switch, hand pendant, BNC trigger cable

TTL Logic Port Splitter Cable

• Y-Connector splitter cable allows 2 devices to be attached to the same TTL logic port
• Example: A Valve Control Box and a Foot Switch
• Adds 11.5 inches to each cable
• Additional splitter cables can be added to attach additional devices

---

USB Converter and RS-232 Primary Cable Kit

• CBL-PC-PUMP-7:  RS-232 Primary Network Cable, 7 ft.
• CBL-USB232:  USB to RS-232 Converter Cable

Pump-to-PC RS-232 Primary Network Cable

• Allows full control of pump or other device from a computer
• DB-9 adapter connects to 9-pin serial port (25-pin adapters available upon request)
• Attaches to the RS-232 communications port of pump or other device
• Available in 7' or 25' length cables
• Quick and easy setup
• Download FREE pump terminal emulator

RS-232 to USB Converter Cable

• Adds an RS-232 serial port to your computer by attaching to a USB port
• 3 ft. Cable.
• Includes software driver CD
• Attaches to RS-232 Primary Network Cable CBL-PC-PUMP-7

Pump-to-Pump Secondary Network Cable

• Allows networking of two or more pumps or other device to a single computer port
• Quick and simple setup
• Utilizes the RS-232 communications port of device
• Available in 1', 7', or 25' length cables
• Requires first device to be connected with primary network cable

Pump Synchronization Cables

• Used for setting up a continuous infusion system, dual infusion system, or one of the many other advanced multi-pump automation modes.
• Establishes a communications link between two pumps using the RS-232 serial ports on the pumps.
• 3 1/2' cable
• Download User Manual

• Used for setting up basic modes of dual pump systems
• Synchronize pumping direction of two pumps so that they change directions, start, and stop as one system
• Utilizes the TTL logic port on pump
• 7' cable

PC Communication with a Dual Pump System

• Enables PC communications with a Dual Pump system connected with cable CBL-DUAL-3
• Kit includes cable CBL-DUAL-6, plus all other cables necessary to setup a Dual Pump system connected to a PC
• See User Manual for a detailed description: Download User Manual

• Enables PC communications with a Dual Pump system connected with cable CBL-DUAL-3
• Replaces cable CBL-NET-7 in cable CBL-PC-PUMP-7
• Individual cable CBL-DUAL-6 only
• 3 1/2' cable

Lockout Mode Disable Key

• For use with a syringe or peristaltic pump's Lockout Mode
• Prevent unauthorized or accidental changes to the settings by locking the keypad
• The Lockout Disable key unlocks the keypad and allows settings to be changed
• Attaches to the TTL logic port on the syringe or peristaltic pump
• Quick and easy setup

---

OEM Starter & Net Kits:

• For interactive communications or uploading of programs to an OEM syringe pump from a computer
• Includes: Power supply, Pump-to-PC RS-232 primary network cable (CBL-PC-PUMP-7), RS-232 to USB converter cable (CBL-USB232), and user manual.
• Download our free pump terminal emulator or get a trial version of our Windows based SyringePumpPro

• For networking an OEM syringe pump's communications through another pump
• Use one additional OEM-NET for each additonal pump added to the network
• Includes Power supply and secondary cable (CBL-NET-7) only.

---

Power Supply Daisy Chain Connector Extension Cable

• Power multiple pumps from a single power supply
• Attaches to power supply DC cable
• Adds power connectors for up to 10 pumps
• 10" between connectors
• Maximum 4A total load
• Cable only

---

Single Valve Control Box

• Attach your 12V DC valve and the control box will open or close your valve according to the pumping direction
• Valve active direction selection switch
• Utilizes the TTL logic port on pump
• ADPT-VALVE-INTERFACE-1-US Includes power supply for valve

Dual Valve Control Box

• Attach your two 12V DC valves and the control box will open or close your valves according to the pumping direction of each pump
• Valve active direction selection switch
• Utilizes the TTL logic port on each pump
• Includes cable CBL-DUAL-3 for synchronized pumping between two pumps
• ADPT-VALVE-INTERFACE-2-US Includes power supply for valves
